Applications
Automatic Carton Box Packing Machine for Bottle And Ointment is specially used for cartoning pharmaceutical bottles such as:ointment.Aluminum bottle and plastic bottle.The machine could fold the leaflet,open the carton and form ointment bottles automatically,these actions could bo finished by synchronization,the machine also could make the code printing on the catons.The machines is controlled by PLC.
Performance and characteristic
Speed frequency transformer,machine interface and touch screen operation system,it will show the cartoning speed and cartons counting.The machine is versatile for cartoning many carton sizes within the permitted range by adjusting and without changing parts.The machine is also equipped with automatic detecting system,it could reject the inferior carton and stop machine by positioning.The touch screen can show the problem and soution of elimination.
Main technical parameters
Cartoning speed | 50-100 Carton/min | |
Carton | Request | 250-350g/m2(addcording to carton size) |
Specification | (50-200)×(20-80)×(14-45)mm | |
Leaflet | Request | 55-65g/m2 |
Folded Leaflet Specification(1-4) Fold | (80-240)×(90-190)mm (L×W) | |
Compressed air | Pressure | ≥0.5Mpa |
Consumption | 120-160L/min | |
Motor Power | 220V 50HZ 0.75kw | |
Dimension | 4200×1200×1600mm (L×W×H) | |
Net weight | 1600kg |
