Manufacturer User Boundary Switchgear Switch Cabinet

Manufacturer high voltage user boundary switchgear distribution panel board General introduction          The KXGN - 12 type user demarcation switch cabinet equipment widely used in cables of rated voltage 12kV, rated frequency 50Hz tap, segme

Technical Feature

  • Shanghai, China
  • 5000PCS/Year
  • L/C, T/T, D/P, Western Union, Paypal
  • CCC, ISO9001
  • Stainless Steel
  • High Voltage
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$11~7

PRIMARY PARAMETERS

Model NO.
KXGN-12
Rated Voltage
12kv
Rate Current
630A
Trademark
keyu Electric
Transport Package
Standard Export Wooden Case
Specification
200KG
Origin
China
HS Code
8535210000

DETAIL DESCRIPTION

Manufacturer high voltage user boundary switchgear distribution panel board

Manufacturer User Boundary Switchgear Switch Cabinet Manufacturer User Boundary Switchgear Switch Cabinet

General introduction

    The KXGN - 12 type user demarcation switch cabinet equipment widely used in cables of rated voltage 12kV, rated frequency 50Hz tap, segmented, and multiple power point contact, applicable to the city underground cable ring and radiant power line and the control and the connection, and underground cables and overhead line hybrid net import line control and connection, realize the ring network power supply and radiation power. The product has the unique function of automatically removing branch line, grounding fault and interphase short circuit fault, which is called the function of dividing switch cabinet or watchdog function. It is a new high-tech product integrated with vacuum switch cabinet technology and microelectronic intelligent control technology.



Reference standard

GB/T11022  Common technical requirements for high voltage switchgear and control equipment standards
GB 39063.6kV ~ 40.5kV AC metal closed switch equipment and control equipment
GB 1984  High voltage AC circuit breaker
GB 311.1 Insulation coordination of high voltage transmission and transformation equipment
GB/T3309 Mechanical test of high voltage switchgear at normal temperature
GB 4208Shell protection level (IP code)
GB/T191   Packaging, storage and transportation, illustrations
DL/T404 3.6kV ~ 40.5kV AC metal closed switch equipment and control equipment

Technical Parameters:
Manufacturer User Boundary Switchgear Switch Cabinet

Factory Instruction


     Keyu Electric Co.,Ltd was established in 2005,located in Jiangsu Province with a registered capital of 60 million Yuan. Keyu  covers  an area of more than 20,000 square meters. We're a national high-tech enterprise that specializes in manufacturing medium and  high voltage circuit breakers, switchgear and substation. We are qualified suppliers of China National Power State Grid. Keyu is a well-managed enterprise with a skillful staff team and strong technical capability, equipped with domestically first-grade device of production and examination. We are certified by ISO9001:2000 system. A majority of our products have obtained CCC certificate (China compulsory certificate). We are one of the first batch electric appliance manufactures who have obtained 3C certification.
      We offer sevices:over 100 First-class engineers and researchers dedicated in the product and service innovation.Experienced sales and logistic team to operate the transaction and shippment smoothly.Skilled workers and advanced manufacturing equipment gurantee the production and quality well.Professional QC team to gurantee the terminal quality.Good after-sales service to settle any question from our customer and give prompt reply and solution scheme.
    We provide competitive prices, high quality products, timely shipment and efficient services to develop our cooperation with all of our customers. We would like to extend business with the customers and partners from all over the world on the basis of cooperation and mutual benefit.


Manufacturer User Boundary Switchgear Switch Cabinet


Certifications and patents
Manufacturer User Boundary Switchgear Switch Cabinet




Manufacturer User Boundary Switchgear Switch Cabinet
FAQ:

1. Are you the manufacturer or trader?
Keyu Electric is a leading & professional manufacturer .

2. What is your main markets?
Our main market is in home & a half in South-East Asia, Middle East,West-Africa, East-European countries & Some South America..etc

3. What is your delivery & after-sales serive?
The delivery is according to order qty, normally for containers order we need 1 month. Per each month 20 containers (20'ft or 40'ft)are no problem for us . We can answer user's question and solve their problem in 24 hrs per each day and give full technical support in time to all of our products.

4. What is your product warranty?
Firstly we have quality certificates like CCC, ISO9001..etc for our switchgears & power equipments ,have CE,Rohs,CB,TUV,Kema..for their electrical parts and accessories. Secondly we supply 1 year quality guarantee,during this period we supply free repair,maintenance and technical support.Certainly for some of switchgears and power equipments, their using life is over 20 years,no problem.

5.Do you accept OEM and ODM?
Yes.  Our R & D team owns latest technology ,can develop & produce products as customers' drawing & under their brand

6. What is your payment terms?
a. 30% T/T in advance as deposit ,balanced before  shipping..
b. irrevocable L/C at sight for order which amount is over 100 thousand USD
C. for old business partner,we can negociate together for other special terms
d . For samples, we accept T/T,Western union, moneygram, paypal..etc

Our Services
1.Your inquiry related to our product & price will be replied within 24 hours
2.Well-trained & experienced staff are to answer all your inquiries in English
3.Working time: 8:00am ~17:45pm, Monday to Saturday. (UTC+8)
4.Customized solution & perfect after-sale service
5. For large order, engineer can be sent to your country for on-site mainternace instructions.
6.Our advantage:a.Competitive price  b.Good quality  c.Timely delivery  d.New model launch yearly e.we are factory.
