High Quality Low prices Image Particle Analysis System
General Description
1. This image analysis system for particle size is multi-functional including image distribution test and particle size analysis.
2. The image analyzer for particle size is the integration of the traditional microscopy and advanced image processing technology, it consists of optical microscope, CCD camera, image acquisition system, computer, printer, etc.
3. The basic operation is performed by
A. Firstly taking the picture of the image in microscope by a special camera,
B. Secondly transmit the image obtained to the computer by image acquisition system, thirdly process and analyze the image in special particle size analysis software,
C. Finally output the result through monitor and printer.
4. It is characterized by direct-image, direct-view, accuracy, broader range, automatic recognition, statistics and quantification.
5. In addition to examining the shape of the particle, it gives particle size distribution analysis and the ratio of length to diameter (L/D), etc...
6. Therefore it becomes a new method for particle size test in scientific research and production field.
For more detail info, please feel free to visit our website or inquire us at any of your convenience.
http://www.magnetequip.com/
General Description
1. This image analysis system for particle size is multi-functional including image distribution test and particle size analysis.
2. The image analyzer for particle size is the integration of the traditional microscopy and advanced image processing technology, it consists of optical microscope, CCD camera, image acquisition system, computer, printer, etc.
3. The basic operation is performed by
A. Firstly taking the picture of the image in microscope by a special camera,
B. Secondly transmit the image obtained to the computer by image acquisition system, thirdly process and analyze the image in special particle size analysis software,
C. Finally output the result through monitor and printer.
4. It is characterized by direct-image, direct-view, accuracy, broader range, automatic recognition, statistics and quantification.
5. In addition to examining the shape of the particle, it gives particle size distribution analysis and the ratio of length to diameter (L/D), etc...
6. Therefore it becomes a new method for particle size test in scientific research and production field.
| Size Range | 1-3000μ m |
| Max Ampl. | 1600 |
| Max Resolution | 0.1μ m |
| Repeatability | < 3%(error results from sample preparation not considered) |
| Particle size distribution type | volume, area, number, L/D |
| Output Items | Original parameter (including sample information, test information, etc) |
| analysis data (including differential distribution, cumulative distribution, average diameter, the ratio of length to diameter (L/D), etc. ) | |
| analysis data (including differential distribution, cumulative distribution, average diameter, the ratio of length to diameter (L/D), etc. ) |
