Application fields
Suitable for samples with narrow distribution range (the ratio of maximum size to minimum size is less than 30).
Abrasives: such as silicon carbide, corundum, diamond, garnet, etc.
battery materials: spherical graphite powder, etc.
metal powder: such as spherical aluminum powder, lead tin alloy powders and other atomized metal powder.
Nonmetal powder: such as glass beads, polystyrene, etc.
acicular powder: such as wollastonite, etc.
biological agents: such as cell.
Foods: such as milk, flour, etc.
others: such as scientific research, teaching, etc
Not applicable fields
Superfine powder: sample with D50 less than 4 micron.
Sample with wide size distribution: such as ratio of maximum size to minimum size is more than 30.
Samples that can't use water and ethanol as its medium.
Samples whose particle size is more than 400 microns.
| Size Range : | 4-400 um |
| Magnification: | 5-35 X |
| Maximum resolution: | 0.5 um |
| Repeatability: | < 1% |
| Accuracy: | < 1% |
| Test items: |
(1) particle size: particle size distribution, typical value, maximum particle size, specific interval content, content of particle that is bigger than or less than a certain size. (2) Particle shape: length to diameter ratio and its distribution, circle fit and its distribution, particle image. (3) Particle counting: measuring the number of particles in a specific volume of liquid. |
| Output items:. | Original parameters (including sample information, test information, etc.), analyzed data (including particle size distribution, distribution of the length to diameter ratio, distribution of circle fit, and its typical data, etc.), distribution pattern (interval distribution histogram and cumulative distribution curve, etc.) |
