High Pressure Carbon Steel Carbon Steel Safety Control Valve

DN(mm): 10, 20, 30Pressure setting(bar): 210, 315Discharge: Manual dischargeBlock material: Carbon steelSeal material:NBR, EPDM, FPM(viton)Pressure relief valve: Adjustable using spannerThread connection: ISO 228, DIN13(metric ISO965/I)

Technical Feature

  • Ningbo, China
  • 100000
  • T/T
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$55~200

PRIMARY PARAMETERS

Model NO.
SAF
Safety & Shut-off Block Valve
Material
Carbon Steel
Hydraulic High Pressure Safety Control Valve
Trademark
XH
Specification
SAF-10, SAF-20, SAF-32
HS Code
84812010
Safety Control Valve
Accumulator Control Valve
High Pressure
Safety Control Valve
Hydraulic High Pressure
Carbon Steel Hydraulic High Pressure Safety Valve
Transport Package
Carton/Pallet
Origin
China

DETAIL DESCRIPTION

DN(mm): 10, 20, 30
Pressure setting(bar): 210, 315
Discharge: Manual discharge
Block material: Carbon steel
Seal material:NBR, EPDM, FPM(viton)
Pressure relief valve: Adjustable using spanner
Thread connection: ISO 228, DIN13(metric ISO965/I)
High Pressure Carbon Steel Carbon Steel Safety Control Valve
High Pressure Carbon Steel Carbon Steel Safety Control Valve
High Pressure Carbon Steel Carbon Steel Safety Control Valve
High Pressure Carbon Steel Carbon Steel Safety Control Valve
High Pressure Carbon Steel Carbon Steel Safety Control Valve
High Pressure Carbon Steel Carbon Steel Safety Control Valve
