Stainless steel 2PC Ball valve Light Type 1000WOG
- Model: WB-02T8
2. Name: 2PC Ball Valve
3. Size: 1/4"~4"
4. Material: CF8M/CF8,SS316/SS304,1.4408/1.4301
5. Design Standard: ASME B16.34
6. Pressure: 1000WOG/PN64
7.Temperature: -29°C~180°C
8. Application: water,oil,gas
9. Thread: NPT,BSPT,BSP,DIN,MPT
10. Advantage: Fluid resistance small, Structure is simple, Small volume, lightweight , Easy to operate, Opening and closing rapidly, Convenient maintence.
1.Blow-out Proof Stem
2.Pressure Balance Hole In Ball Slot
3.Various Thread Standards Avaliable
4.Lock Device
STANDARDS:
Design: ASME B16.34
Wall Thickness: ASME B16.34
Pipe Thread: ASME B1.20.1, BS21
DIN 2999/259, ISO228/1, JIS B 0203, ISO7/1
Face to Face: ASME B 16.10
Butt Weld: ASME B16.25
Inspection & Testing: MSS SP-110, EN 12266
Main Material
| Part name | Materials |
| 1.Body | SS201 SS304 SS316 SS316L WCB |
| 2.Bonnet | SS201 SS304 SS316 SS316L WCB |
| 3.Valve seat | PTFE, RPTFE, PPL |
| 4.Ball | SS201 SS304 SS316 SS316L |
| 5.Seal ring | PTFE, RPTFE, CPTFE |
| 6.Stem | SS201 SS304 SS316 SS316L |
| 7.Packing | PTFE, RPTFE, PPL |
| 8.Gland | SS201 SS304 |
| 9.Handle | SS201 SS304 |
| 10.Nut | SS201 SS304 |
FAQ
Q1: We are interested in your products?
A1: In order to recommend you suitable products, please provide detail information, like size, material, pressure, model.
Q2: Is the requirement for MOQ?
A2: For some small size, like 1/4''-1''(DN6-DN25), it request the MOQ is 100pcs for each size. Generally speaking, it depends on your order.
Q3: How about the warranty?
A3: The warranty time is 12 months after leaving our factory.
Q4: Payment
A4: Mainly T/T, L/C.
Payment Term: 30% in advance, 70% balance paid before shipping or against copy of BL.
Q5: Can you manufacture different standards valves according to customer requirements?
A5: Yes. We can manufacture ANSI,DIN, JIS standards for different pressure & temperature & size according to different needs.
If you want to know more about our products, please contact freely. We will patiently answer your all questions.
