Specifications
1.DN50-1200(2"~48")
2.PN10/16(150/200PSI)
3.API, ANSI, ASME, DIN, BS,JIS, ISO approved
4.material:CI,DI,WCB,SS,ALB,brass,etc.
Wafer Type Butterfly Valve with Handle, Wormgear, Pneumatic, Electric Driver
Features:
1.Small in size and light in weight. Easy installation and maintenance. It can be mounted wherever needed.
2.Simple and compact construction, quick 90 degree on-off operation.
3.Flow curve tending to straight line. Excellent regulation performance.
4.Long service life. Standing the test of thousands opening/closing operation.
5.Wide selection of materials, applicable for various media.
Standard:
Design standard | Face to face | End flange | Test & inspection |
MSS SP-67 API609 EN593 | API609 ISO5752 series 20 BS5155 | DIN PN10/16/25 ANSI B 16.1 BS4504 ISO PN10/16 JIS B 2212/2213 BS 10 table D BS 10 table E | API 598 |
Performance:
PN(MPa) | DN(mm) | Testing Pressure (MPa) | Applicable Temp. °C | Applicable Medium | |
Shell | Sealing | ||||
1.0/1.6 | DN50 ~ DN1000 | 1.5 | 1.1 | -45~ 150 | Fresh water, Sewage, Sea water, Air, Vapor, Food, Medicine, Oils, Acids, Alkalis, etc. |
Material List:
Part Name | Material |
Body | CI/DI/WCB/SS |
| Disc | DI/ALB/WCB/MONEL/CF8/CF8M |
| Stem | SS416/SS304/SS316/WCB |
| Seat | EPDM/BUNA/NBR/NR/PTFE/HYPALON/VITON/NEOPRENE |
