Technical Parameter
[Spec]: 3T-180T,6m-60m , 0.55KW-75KW
[Material]: SUS304 SUS316L,
The pump body, pump cover and impeller contact with medium made of SUS316L, SUS304.
[Standards]: DIN SMS
[Impeller]: Open type impeller, there is no blind corner.
close type impeller,
semi-open type impeller
[Operate condition]:
Sanitary centrifugal pump is close to HORIZONTAL transport of high and low level, is not the Self-priming type.
[Surface treatment]:
The part contact with mdedium is Polished,
And other part is Sand Blasted
[Max inlet pressure]:
0.5MPa
[Temperature range]:
-10 to Degree +140 Degree(EPDM)
[Flushable mechanical sealing: ]
Water pressure: __Max 0.1MPa
Water lift: _______0.25-0.5L/min
| Flow (Ton) per hour | Unit (SS304 explosion proof ABB motor) | Unit(SS316L ABB explosion proof Motor | Motor made in Chian ss304/316L) | Inlet/Outlet(mm) | Lift(Meter) |
| 1T(0.55KW) | 300 | 330 | 260/300 | 32/25 | 15 |
| 3T(0.75KW) | 350 | 350 | 315/350 | 38/32 | 20 |
| 5T(1.5KW) | 500 | 550 | 450/500 | 51/38 | 25 |
| 10T(2.2KW) | 550 | 600 | 500/550 | 51/38 | 25/32 |
| 15T(3KW) | 750 | 800 | 670/735 | 51/51 | 32/42 |
| 20T(4KW) | 780 | 850 | 720/780 | 51/51 | 36/52 |
.............................................150Tons per hour the biggest one we can produce.
[Motor]:
1. Configuration of "ABB" brand three-phase AC motor is in accordance with the International Electrotechnical CommissionIEC60034. IEC60072 standard design comply with European "CE" Marking requirements
2. The Explosion-Proof motor also available, that can meet with the requirement of different Applications.
3...It has excellent electric performance, low niose and low vibration.
The protection grade is IP55, insulation grade is F.
4. Operate involtage:
≤ 3Kw, 220-240V/380-420V, Δ /Y
> 3Kw, 380-420V/660-690V, Δ /Y
5. Requency: _________50Hz/60Hz
6. Working method: ____Continuous(SI)
7. Rotate speed: ______The standard rotate speed is 2900r/min
PS: performence curve could be provided~
HONGTAI is specialized in Manufacturing
- Sanitary PumpsSanitary ValvesSanitary Pipe fittings etc. ,
which can be widely used in food, beer, beverage, dairy products, cosmetic, pharmacy and biology engineering field.
For that our products will be applied in the fluid systems with strict sanitary and sterilizing requirement, so we do have many strict tests for our products, such as the performance curve test of pumps, frequency curve, the smooth and clean test, pressure test and so on.
All the commodities are made in accordance with the standards of ISO, IDF, DIN and 3A.The technology is comparable to the international level in the same field and the quality complies with the requirements of GMP. And the production of YUY is based on advanced manufacture technology and a high sense of responsibility, so that we can provide our customers the products with high quality and high precision.
In addition, our R&D department can explore new products according to out customers' particular requirement. And our production capacity is very great and efficiency, so we can supply the products with best delivery date.
Under the principle of that "the customers are our best inspectors; the market is the most impartial judge of enterprises; our mission is to provide good quality products with competitive price and satisfactory service for our customers HONGTAI believe that our honesty, enthusiasm and enterprise will win your support .We are looking forward to starting cooperation, and establish mutual-benefit relationship with our customers, and reach win-win.
