Product features:
1. Kailaili Air Cooler sheet metal pasrt series all use hydraulic or hydraulic punch one-time punched,good appearance,strength structure.
2. Sheet metal parts are crimped aluminum,spay plate,stainless steel plate can be choosed.
3. Use strong insulating U tubular heater pipe,short defrosting time,high efficiency,also can according customer's request to choose the water defrosting or hot freon defrosting.
4. Coil pipe use the thickness cooper tube, improve the service life, aluminum fin use hign efficiency aluminum sheet, through the pipe expansion and impinges on the cooper tube, the effect of heat transfer increase to the top.
5. Using hign efficiency fan, big air volume, far range, low noise, low power consumption, long service life, hign reliability.
6. Product all through the holding pressure filling nitrogen before product leave the factory
Kailaili Refrigeration System is widely used in food, supermarkets, hotels, aquatic products, pharmaceutical, biological, chemical, industrial and mining enterprises and other industries. It can be customized according to customer requirements and library features, the constant pursuit of excellence, has the ability to meet the special requirements of customers, to win customer satisfaction.
DD Technical parameter
1. Kailaili Air Cooler sheet metal pasrt series all use hydraulic or hydraulic punch one-time punched,good appearance,strength structure.
2. Sheet metal parts are crimped aluminum,spay plate,stainless steel plate can be choosed.
3. Use strong insulating U tubular heater pipe,short defrosting time,high efficiency,also can according customer's request to choose the water defrosting or hot freon defrosting.
4. Coil pipe use the thickness cooper tube, improve the service life, aluminum fin use hign efficiency aluminum sheet, through the pipe expansion and impinges on the cooper tube, the effect of heat transfer increase to the top.
5. Using hign efficiency fan, big air volume, far range, low noise, low power consumption, long service life, hign reliability.
6. Product all through the holding pressure filling nitrogen before product leave the factory
Kailaili Refrigeration System is widely used in food, supermarkets, hotels, aquatic products, pharmaceutical, biological, chemical, industrial and mining enterprises and other industries. It can be customized according to customer requirements and library features, the constant pursuit of excellence, has the ability to meet the special requirements of customers, to win customer satisfaction.
DD Technical parameter
| Model | Ref capacity(kw) | Cooling area (m2) | Fin spacing(mm) | Fan motor | Defrost heater | |||||||
| Qty | Dia(mm) | Air volume (m³) | Pressure(pa) | Power(w) | voltage(v) | Coil(kw) | Catchment(kw) | Power supply | ||||
| DD-3.0/15 | 3 | 14.5 | 6 | 2 | 350 | 2*2300 | 90 | 150w | 380v/50hz | 1 | 1 | 220v/50hz |
| DD-4.0/22 | 4 | 22.5 | 2 | 350 | 2*2300 | 90 | 150w | 2 | 1 | |||
| DD-6.0/30 | 6 | 29.5 | 2 | 400 | 2*3200 | 100 | 200w | 2.4 | 1.2 | |||
| DD-8.0/40 | 8 | 40 | 2 | 400 | 2*3200 | 100 | 200w | 2.4 | 1.2 | |||
| DD-12.0/60 | 12 | 60 | 2 | 500 | 2*6000 | 167 | 550w | 4.5 | 1.5 | |||
| DD-15.9/80 | 15.9 | 80 | 2 | 500 | 2*6000 | 167 | 550w | 6 | 1.5 | |||
| DD-20.0/100 | 20 | 100 | 3 | 500 | 3*6000 | 167 | 550w | 6.4 | 1.6 | |||
| DD-24.0/120 | 24 | 120 | 3 | 500 | 3*6000 | 167 | 550w | 6.8 | 1.7 | |||
| DD-28/140 | 28 | 140 | 4 | 500 | 4*6000 | 167 | 550w | 8 | 2 | |||
| DD-32/160 | 32 | 160 | 4 | 500 | 4*6000 | 167 | 550w | 8.8 | 2.2 | |||
| DD-37.4/200 | 37.4 | 199 | 2 | 600 | 2*10000 | 250 | 1.5kw | 12.8 | 1.6 | |||
| DD-46.8/250 | 46.8 | 250 | 3 | 600 | 3*10000 | 250 | 1.5kw | 13.6 | 1.7 | |||
| DD-56.2/310 | 56.2 | 298 | 3 | 600 | 3*10000 | 250 | 1.5kw | 16 | 2 | |||
| DD-70.2/360 | 70.2 | 350 | 4 | 600 | 4*10000 | 250 | 1.5kw | 17.6 | 2.2 | |||
| DD-81/400 | 81 | 401 | 4 | 600 | 4*10000 | 250 | 1.5kw | 21 | 2.2 |
