Plastic squeezing pelletizing machine
1.Plastic Film Pelletizing Machine is used for drying washed film flakes and make it into granules.After film squeezing machine the granules can put into extruder directly.
2. Plastic Film Pelletizing Machine save 3 machines . One dewatering machine,one drying system,and one agglomerator.It almost saved 200kw for one line.
Model | BDX500 | BDX1000 |
DIMENSION | 2450X800X1800MM | 2450X800X1800MM |
INLET SIZE | 700X670MM | 700X670MM |
MOTOR POWER | 18.5KW | 22KW |
ROTATED SPEED | 42R/MIN | 42R/MIN |
CAPACITY | 500-700KG/H | 800-1000KG/H |
DRAINAGE METHOD | DRAIN AT THE BOTTOM | |
MATERIAL OUTLET | FREE FALLING | |
HYDRAULIC STATION MOTOR | 1.5-2.2KW |
Q.What material can used in this machine?
A.PE Film,PP Film,PP Woven Bag,PET Film,PVC Film,HDPE Flim,LDPE Film.
Q.What the moisture of final product?
A.2%-3%
Q.What size of final product?
A.Final product size can be control,the diameter around 6-8mm
Q.Can we put the final product into the extruding machine?
A.yes
IF YOU WANT TO KNOW MORE ABOUT THE MACHINE, PLEASE FEEL FREE TO CONTACT US! (+86 13862001031)
