Product Name

Portable electric air compressor for carbon fiber gas cylinder

Model

FN-100E

Portable electric air compressor application

• Compressed air cylinder filling pump is an air filling device to be used for filling fresh air compressed into gas cylinder of SCBA, is designed for solving the general low pressure of compressed air.
• This device output no oil, no impurities, non-toxic, tasteless, clean high pressure breathing air through purifying function of the two stages of oil-water separation and filter.
• Cylinder Filling Pump can be used for firefighting SCBA, diving, shooting, emergency rescue, chemical, oil and other industries.

Portable electric air compressor parameters

Pic.	Model	FN-100E
	Working pressure	300 Bar 30Mpa 4300 Psi Diving :225Bar 22.5 Mpa 3300 Psi
Charging rate	100L/min 6m3/H 3.5CFM
Filling time cylinder	6.8L 0-300 bar/ 20.4 min 12L 0-200 bar/ 24 min
Driven by	Three-phase electric motor
Power	3 Kw
Noise pressure	83 dB
Dry weight	48 Kg
Dimensions	0.78*0.45*0.62m

Portable electric air compressor work process

The flesh air is compressed, filtered and purified by a air compressor, after air quality analyzer qualified, into the gas bomb components. Then to inflate the cylinder safely in the explosion-proof plenum box.

Portable electric air compressor Features

• Easy to move, Easy to operate
• Maintenance simple
• Stainless steel interstage cooler
• High pressure pneumatic hose 1.2 m.
• Four-cylinder four-pole high-pressure compressor
• Stainless steel fan cover
• Two oil-water separator, two drain valve (optional automatic sewage)
• Carbon molecular sieve filtration system
• When reaches the set pressure, shut down automatically.

Our Team

As an innovative technology company, we have a professional R&D team with a strong sense of responsibility and dedication.  All our engineer  are specialized in safety equipments. This team providing a stable and vigorous development for our company.

Our workshop

We are real factory, can supply OEM services. Custom-made safety products are available.

Our Products

Our leading products include SCBA, advanced breathing apparatus, oxygen respirator, gas mask, gas mask filter cartridge, fire fighting suit, fire entry suit, fire fighting & industrial equipment.

Our products can be applied in many industries, such as fire, petroleum and petrochemical, mining, military, road construction, metallurgy and chemical industry, etc.

Our Certificate

We have got CE, ISO9001, CCC, LA, CNAS certificated, and also own a number of invention patents and utility model patents.

Our Customers

We have participated in many exhibitions at home and abroad, through which we had established friendly relationship with customers. Welcome to visit our company and factory!

Our Company

Our factory is located in Songjiang intelligent S&T industrial park of Shanghai, China.
30 minutes to Hongqiao Airport,
40 minutes to Pudong International Airport,
60 minutes to Hangzhou City.
