sales for nuclear power steam turbine from Shanghai electric power station equipment co., LTD., the steam turbine factory

High temperature high pressure condensing steam turbine, extraction condensing steam turbine, high temperature & pressure prefix steam turbine is specially designed and manufactured for iron & steel industry and thermoelectric reformation. To improve energy utilization and energy conservation & emissions reduction has made a new contribution.

C series are single casing & single shaft or double casing & double shaft extraction condensing steam turbine. The inlet parameters are from 1.27MPa/350°C to 13.23MPa/550°C, outputs are 3MW, 6MW, 12MW, 15MW, 20MW, 25MW, 50MW, 75MW with 8 modes and 32 series totally. The speed of turbine is 3000rpm and turbine connects with generator directly

 series steam turbines are single casing & single shaft and multistage back pressure steam turbine. The inlet parameters are from 1.27MPa!350°Cto 13.23MPa/550°C, exhaust pressures are from 0.2Mpa to 5.88Mpa, outputs are 3MW, 6MW, 9MW, 12MW, 15MW, 20MW, 25MW, 40MW, 50MW with 9 modes and 27 series totally. The rotation speed of turbine depending on the design requirements, from 3000rpm to 10000rpm differently. Most of them directly connect to the generators and some others connect to generators by reduction gear box.
