Product Application
KGL long-shaft pump is mainly used for transporting media such as brine, seawater, oxide-scale water and saline wastewater, applicable to various industries including petrochemical engineering, metallurgy, mining, chemical engineering, papermaking, power plant, industrial water supply and drainage, seawater and sewage treatment. The temperature of the medium conveyed by this pump is lower than 85℃ and the maximum concentration of the medium liquid is 50-70% by weight. A small amount of large solid particles are allowed to pass, but the particle size shall not be bigger than 60% of the minimum size of the cross section of passage. It is especially suitable for steel mills to deal with oxide-scale water.
Flow range | 5600-6300m3/h |
Head range | 20-50m |
Outlet diameter range | 900mm |
Submerged depth | 1-50m |
Sichuan Chuangong Industrial Pump Co., Ltd.,established in 1993, is located in zigong, covers an area of nearly 35000 square meters.After more than 20 years of hard struggle, we made glorious achievements in the field of chemical industry pump, impurity pump, submerged pump, sewage pump, fresh water pump, multi-stage pump, etc., and these products are widely used in petroleum, chemical industry, metallurgy, electric power, mining, water supply and drainage, etc.We maintain long-term close cooperation in technology research and development with Sichuan University,Xihua University, Southwest Petroleum University.Our aim is "Strives for the survival by the quality, development of technology innovation, to meet customer expectations, enlarge the markets at home and abroad".Please give us a chance, we will serve you wholeheartedly.
