XD sliding rotary vane vacuum pump
1. Single stage coupling structure
2. High rotary speed, low noise and quick suction
The pump can be cooled by air
3. With oil-return resistant structure, the pump oil is kept from returning to the suctioned system
4. A gas-draining filter fixed in the pump, which operates stably with small vibration can effectively eliminate the oil mist, and can operate under any pressure
5. The pump is widely applicable to several sectors such as food vacuum packing, pharmaceutical, paper convey in printing machines, glass industry convey, vacuum clamps and drying industry etc.
7. Very competitive price
8. 1 year of warranty
9. Short delivery time
Technical Specifications
Model | XD-010 | XD-016 | XD-020 | XD-025 | XD-040 | XD-063 | XD-100 | XD-160 | XD-250 |
Suction speed(m3/h) | 10 | 16 | 20 | 25 | 40 | 63 | 100 | 160 | 250 |
Utmost pressure(Pa) | 2x102 | ||||||||
Motor power(kw) | 0.37 | 0.37 | 0.75 | 0.75 | 1.1 | 1.5 | 3 | 4 | 7.5 |
Speed(rpm) | 1440 | 1440 | 2800 | 2800 | 1440 | 1440 | 1440 | 1440 | 1440 |
Oil capacity(L) | 0.5 | 0.5 | 0.5 | 1 | 1.5 | 2 | 4 | 9 | 9 |
Size of suction port | G½ | G½ | G½ | G1¼ | G1¼ | G1¼ | G1¼ | G2 | G2½ |
Weight(kg) | 16 | 18 | 19 | 19 | 60 | 22 | 115 | 145 | 200 |
Voltage(V) | 380/220 | 380/220 | 380/220 | 380/220 | 380/220 | 380 | 380 | 380 | 380 |
