electric high pressure small self priming water pump dc 12v with built-in fan
| Product name | self priming water pump dc 12v |
| Model number | 0142YB-12-80fsk |
| Voltage | dc 12v (24v is also in stock) |
| Power | 80w |
| Flow rate | 5.5L/Min |
| pressure setting | 131PSI (9BAR) |
| max Working pressure | 79.75PSI (5.5BAR) |
| Allowed medium temperature | 0-70 centigrade |
| Suction distance | 1.5m |
| Lift | 55m |
| range | 8m |
| Color | black |
| Protective valve type | Automatic switch type |
| Specifications | 16.5cm(L) X 9.5cm(W) X6cm(H) |
| Weight | 0.8kg/pcs |
| Corrosion resistant | yes |
| Rubber bracket | can absorb shock when pump working |
we also have other pump for choosing.
| Model no | Voltage | protect valve | power | pressure switch max.value | max.Working pressure | Flow rate | Suction distance | Lift | Range | Connection |
| 0142-15 | 12v | pressure switch or return valve | 15w | 6bar (87psi) | 3.5bar (50.75psi) | 1.5L/M | 1m | 35m | A/B/C/D | |
| 0142-30 | 12v 24v | pressure switch or return valve | 30w | 7bar (101.5psi) | 4bar (58psi) | 3L/M | 1m | 40m | A/B/C/D | |
| 0142-45 | 12v | pressure switch or return valve | 45w | 7.5bar (108.75psi) | 4.5bar (65.25psi) | 4L/M | 1m | 45m | A/B/C/D | |
| 0142-60 | 12v 24v | pressure switch or return valve | 60w | 8bar (116psi) | 5bar (72.5psi) | 5L/M | 1.5m | 50m | 7m | A/B/C/D |
| 0142-80 | 12v 24v | pressure switch or return valve | 80w | 9bar (130.5psi) | 5.5bar (79.75psi) | 5.5L/M | 1.5m | 55m | 8m | A/B/C/D |
| 3210-80 | 12v 24v | pressure switch or return valve | 80w | 10bar (145psi) | 6bar (87psi) | 6L/M | 1.5m | 60m | 8m | A/B/C/D |
| 3210-80 | 12v 24v | pressure switch or return valve | 100w | 11bar (159.5psi) | 7bar (101.5psi) | 8L/M | 1.5m | 70m | 9m | A/B/C/D |
If you order for personal use, you can order in our offical website on aliexpress and choose you liked shipping method.
There are many feedback from world buyers, including buyers from your country.
it can be sent out in 2 working days. Here is the link:
https://www.aliexpress.com/store/group/DC-pressure-water-pump/1229091_501698909.html?spm=2114.12010612.0.0.76e52939D3YZ26&origin=n&SortType=orders_desc&g=y
Applications(Multi-purpose)
- Clean floor, carpet, car, air conditioner
- Home use for garden sprinklers, shower
- Agricultural purposes: spray for farm chemical, pesticide
- Water taps in the boat, caravan or motor home
- Increase piping pressure
Automatic switch type
- When you close the final outlet terminal end, pump will automatically cut off power and motor stop once reach maximum pressure setting value.
- When you open the terminal outlet end, and pump will start running.
- This type has strict requirements on the size of water gun outlet( advice>= dia 1.5mm / 1.8mm), otherwise it can't work properly or even been damaged.
Return valve type
- This type have no strict requirement on the size of water outlet.
- When the water outlet hole is too small or blocked, the motor won't stop running. The return valve will open and the water will cycle in the pump.
- Its working pressure can be controlled by screwing the little screw in front of the pump.
Caution:
Pump must be used in dry condition, it can't be submerged in water.
In winter, in case of frost crack, the water in the pump and pipe must be drained after using.
