CNP high pressure Water Pump/centrifugal pump
Advantages
Energy-efficient
compact structure
Pipeline installation
Small space required
Vertical multistage stainless steel centrifugal pump
Application:
Cooling water system
Municipal water supply and boosting
Domestic water supply
Irrigation
General industrial services
Washing plants
Boiler feed and condensate system
Water treatment
Performance range
Capacity: Q up to 240CBM/h
Head: H up to 305m
Temperature: T up to 120°C
Speed: n 2900rpm or 3500rpm
Power: P up to 110kw
Standard material
All the parts contact with liquid made of 304 SS, 316SS on request. The pump head and suction & discharge can be made of cast iron on request too.
Feed Water Pump
50 Hz | 60 Hz | Q*H | Connection | Voltage | RO SYSTEM |
CDLF 4-4 / 0.75KW | CDLF 4-3 / 1.1 KW | 2.0 t/h * 35m | Flanged | 220V/380V/3Phase | 6000 GPD |
CDLF 4-4 / 0.75KW | CDLF 4-3 / 1.1 KW | 2.5 t/h * 32m | Flanged | 220V/380V/3Phase | 9000 GPD |
CDLF 4-4 / 0.75KW | CDLF 4-3 / 1.1 KW | 3.5 t/h * 30m | Flanged | 220V/380V/3Phase | 12000 GPD |
CDLF 8-4 / 1.5 KW | CDLF 4-4 / 1.5 KW | 5.5 t/h * 40m | Flanged | 220V/380V/3Phase | 18000 GPD |
CDLF 8-4 / 1.5 KW | CDLF 8-3 / 2.2 KW | 7.0 t/h * 38m | Flanged | 220V/380V/3Phase | 24000 GPD |
CDLF 16-3 / 3 KW | CDLF 8-3 / 2.2 KW | 10.0 t/h * 40m | Flanged | 220V/380V/3Phase | 36000 GPD |
CDLF 16-3 / 3 KW | CDLF 16-2 / 4 KW | 12.0 t/h * 38m | Flanged | 220V/380V/3Phase | 48000 GPD |
CDLF 16-3 / 3 KW | CDLF 16-2 / 4 KW | 15.0 t/h * 34m | Flanged | 220V/380V/3Phase | 60000 GPD |
CDLF 20-3 / 3 KW | CDLF 20-2 / 4 KW | 18.0 t/h * 37m | Flanged | 220V/380V/3Phase | 72000 GPD |
CDLF 20-3 / 3 KW | CDLF 20-2 / 4 KW | 22.0 t/h * 33m | Flanged | 220V/380V/3Phase | 90000 GPD |
CDLF 32-30-2 / 5.5 KW | CDLF 32-20-2 / 5.5 KW | 28.0 t/h * 38m | Flanged | 220V/380V/3Phase | 120000 GPD |
Note: Other models per request
