| Pumping detergent:washing machine,dishwashing machine etc. | Analytical instrument:test sampling |
| Printing equipment:pumping ink | Food machinery:beverage,coke syrup machine etc. |
| Kitchen equipment | Laundry equipment |
1. JIHPUMP newest peristaltic pump researched and developed by Jieheng Co,provided with advanced technology and reliable
quality
2. Entrance and exit of pumped fluid are on a straight line,in the vertical route system,fluid can pass by via the shortest path
3. Dismountable press-tubing structure,to ensure operator to change tubing very quickly
4. 3-roller design,to guarantee flow rate maximization
5. Compact structure design,to occupy minimal space and offer more possibilities for your system minimization
6. Assemble tubing 24# & 35# of wall 2.4mm,to pump viscous fluid easily
7. Stepper motor,DC gear motor,DC planetary gear motor & DC brushless planetary gear motor available
8. Mounting hole designed on pump base,no need to prepare mounting panel by users,to save application cost
Parameter
| Model # | 313KA/ZLX | 313KA/ZL | 313KA/WTT | 313KA/BT |
| Rotation speed | 150rpm, 300rpm | 166rpm, 326rpm | 150~290rpm | 0.1~300rpm |
| Product picture |  |  |  |  |
| Tubing | 24# (ID 6.4mm,wall 2.4mm) 35# (ID 7.9mm,wall 2.4mm) | |||
| Flow rate | 975~1433ml/min | 537~1738ml/min | 467~1380ml/min | ≤1500ml/min |
| Motor power | 48W | 6-16W | 48W | 72W |
| Motor | DC planetary gear motor | DC gear motor | DC brushless planetary gear motor | stepper motor |
| Drive | JIHPUMP controller for DC motor optional(pulse width governing speed) | with drive itself | driver optional,please select JIHPUMP controller for stepper motor | |
| Operation voltage | 12V,24V | 12V,24V | 12V,24V | 6~36V |
| Product weight | 620g | 735g | 615g | 920g |
| Pump material | PA66 | |||
| Roller material | Swiss high-function plastics |
| Model # | 313KA/ZLX | 313KA/ZL | 313KA/WTT | 313KA/BT | |
| Rotation speed | 300rpm | 166rpm | 326rpm | 150~290rpm | 0-300rpm |
| 24#(6.4×2.4) | 975 | 537 | 1055 | 467-902 | 0-975 |
| 35#(7.9×2.4) | 1433 | 885 | 1738 | 714-1380 | 0-1500 |
