Silver Double Limited manufactures various equipment related to bio-process for biotechnology, biochemical, pharmaceutical, agricultural, environment, life science industry.

Technical Feature

  • Fermenting Equipment
  • New
  • Jilin, China (Mainland)
  • Sidolim
  • SDL-F-31
  • Alcohol, Carbonated Beverage, Coffee, milk...
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$3~48

PRIMARY PARAMETERS

Processing
Fermenting Equipment
Condition
New
Place of Origin
Jilin, China (Mainland)
Brand Name
Sidolim
Model Number
SDL-F-31
Processing Types
Alcohol, Carbonated Beverage, Coffee, milk...
Voltage
3phase/380(220)
Power(W)
Varies Depending
Dimension(L*W*H)
Capacity Request
Weight
1000-3000kg
Certification
CE ISO TUV
Warranty
1 year
After-sales Service Provided
Overseas service center available
Material
316 stainless steel Enzyme production fermenter
Commodity
fermenters and bioreactors
Fermentor and bioreactor
brewing equipment
Application
brewery fermenters
Motor
ABB, SIEMENS, SEW, Domestic
Function
material fermenting
Machine type
Chemical Batch Fermenter
Control System
PLC automatic control
Heating method
Jacket Heating

DETAIL DESCRIPTION

stainless steel fermentation tanks | stainless steel fermentation tanks | digesting fermentation tank fermenter
Product Description

Silver Double Limited manufactures various equipment related to bio-process for biotechnology, biochemical, pharmaceutical, agricultural, environment, life science industry. Especially, SiDoLim's high performance of Beer Brewing Equipment brewing System system is applicable for both research and industrial bio-processing facilities.



The SiDoLim Beer Brewing Equipment brewing System is a price compatible lab scale fermentation system for microorganisms which has functions of temperature control, air supply, agitation, pH measuring and control.

The 1.5 to 10 liters single-wall-glass type vessel can be applied to SiDoLim Beer Brewing Equipment brewing System. The temperature is controlled by the heater plate, which is located at the bottom of the vessel. The digital PID controlled 200 Watt heater and two air cooling fans are located beneath the heater plate that accurate temperature control is realized. Furthermore, a solenoid valve controls the flow rate of the cold finger, which is attached at the head plate that precise temperature control is possible even for the exothermic reaction. Cold water can be feed to the condenser that media loss by the evaporation can be protected.



The 60 Watt (100Watt is optional) DC servo motor gives wide agitation speed control ranges.  The agitation motor is installed at the top plate and double seal protect the contamination. Built-in diaphragm type air pump supplies oil-less air to the reactor. Digital microcomputer measure and control the pH value of the media with using a Mettle-Toledo pH probe for measuring and two Watson-Marlow peristaltic pumps for acid/base feeding. All the setting parameters and measured values are handled by PID series standalone type microcomputers and displayed by LCD displayers. RS232C serial communication gives all the measured data to the computer or other instruments and analog outputs (0 to 5 Volts) are also supplied.



Furthermore, the DO and antifoam modules are also supplied that the Value-Plus can be extended to the full-scale fermentation system.



Features and Benefits

    Price compatible lab scale fermentation system

    Easy operation & Space savings

    Digital controllers and one LCD displayers

    Various size of vessels can be applied

    Top mounted DC servo motor gives wide agitation speed control ranges

    Built-in diaphragm type air pump protects the oil contamination by air supply

    Digital PID temperature controller gives the accurate and stable temperature condition of Beer Brewing Equipment brewing System

    pH value is digitally measured and controlled

    RS232-C and analog outputs for the temperature and pH value

    The DO meter and antifoam module are also supplied



Fermenting products:

Cheese, draft beer, sausage, bread, soybean flour, fermented milk, steamed bun, brandy, natural wine, fermented bean curd, cane sugar, rice wine...


Application of fermenter:



The fermentor is widely used in dairy products, beverages, bioengineering, pharmaceuticals, fine chemicals and other industries. The tank has interlayer, insulating layer, heating, cooling, and heat preservation. The tank and top and bottom filling head (or conical) are all processed by spinning R angle. The inner wall of the tank is polished with mirror surface, and there is no sanitary dead angle. The full closed design ensures that the material is always mixed and fermented in a non polluted state. The equipment is equipped with air breathing hole, CIP cleaning nozzle, manhole and so on.



Specifications



Vessel

Total Volume

3

5

7

10

Working Vol.

2

3

5

7

Head Plate

thermowell, aeration, sampling, spare ports

pH, DO and foam probe ports

4 feeding ports and 2 general purpose ports

Vessel

Single wall bottom heating

Aeration

Flow rate

0~5 LPM

Sparger

Removable ring sparger

Inlet Filter

0.2 μ m filter interchangeable

Air Pump

Diaphragm pump

Condenser

Water cooled condenser

Air flow meter

0~5LPM, vertical type

Agitation

Servo Motor

Top drive DC motor 60W(100W option)

Magnetic Hall sensor, PWM control

Impellers

2-rushton turbine impellers, 1 foam breaker

Indication

LCD display in 10 rpm increments

Temperature

Controller

Control range

3 o C above ambient temperature to 80 o C

Accuracy

± 0.1   o C

Sensor

RTD(Pt-100)

Control Algorithm

PID

Heating

200 Watt heater

Cooling

Air fan and fin for air cooling and

Solenoid valve for water cooling

Interface

RS232-C

Output Signal

0 to 5V analog signal for data recorder

pH controller

Probe

Mettle-Toledo pH: 2.0~12.0

Calibration method

(4,7), (4,7,10), (7,10) and manual adjust

Measuring

pH 0.01 resolution

Control

Digital PWM, pH 0.1 accuracy

Peristaltic pump

2- Watson-Marlow 102R peristaltic pump

DO

controller

Set point Range

0~200%

Display Range

0~200%

Control Mode

PID

Resolution

0.1

Accessory

4 reagent bottle, Reagent bottle holder

Power

110~220Volt/50~60Hz

Dimension

D ´ W ´ H(mm)

450 ´ 250 ´ 670

Weight

Kg

100





Product Pictures













Shipment
Payment

T/T, MoneyGram, Paypal, Western Union, L/C...

Contact





FAQ

1) How can I place order?
A: You can contact us by email about your order details, or place order on line.

2) How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank) and Paypal, Western Union are the most usual ways we are using.

3) What's the order procedure?
A: First we discuss order details, production details by email or TM. Then we issue you an PI for your confirmation. You will be requested to do pr -epaid full payment or deposit before we go into production. After we get the deposit, we start to process the order. We usually need 7-15days if we don't have the items in stock. Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.

4)How do you take care when your clients received defective products?
A: replacement. If there are some defective items, we usually credit to our customer or replace in next shipment.

5)How do you check all the goods in the production line?
A: We have spot inspection and finished product inspection. We check the goods when they go into next step production procedure.

Our Service

A: Your inquiry related to our products or prices will be replied in 24 hours.
B: Protection of your sales area, ideas of design and all your private information.
C: Best quality and competitive price.
