2018 QJYL factory stainless steel seed tank series

PRIMARY PARAMETERS

Processing

Fermenting Equipment

Condition

New

Place of Origin

Shanghai, China (Mainland)

Brand Name

QJYL

Model Number

Custom-design

Processing Types

Milk

Voltage

Adjustable

Power(W)

0.45-0.75

Dimension(L*W*H)

Capacity

Weight

100-2000kg

Certification

ISO9001

Warranty

1 Year

After-sales Service Provided

Engineers available to service machinery overseas

Material

Stainless Steel

Function

storage, heating, fermenting, mixing ,cooling liquid Heating method

Name

Micro Brewery Equipment

Application

Dairy, food, beverage, chemical,

Product Name

stainless steel seed tank series

Keywords

Beer Fermentation Tank Used

Capacity

100-600L

Construction

Horizontal and vertical; Open lid,

customized design

Heating method

Steam/ electricity/hotwater

DETAIL DESCRIPTION

Product Description

2018 QJYL factory stainless steel seed tank series

Applicable range

1,Commonly applicable for incubating work fermentation agent for acidophilus milk .

2,Ideal in fields such as foods,diary product,fruit juice beverages,pharmacy,chemical industry and biological engineering etc.

Structure characteristics

1,Adopt structure of internal package,with heat preservation materials inside

2,Materials are all sanitary stainless steel.

3,Humanized structure design and easy to operate.

4,Transition area of interior wall on tank adopts arc for transition to ensure no dead corner of sanitation.

5,Top heat sealing adopts rotary opening type.For tank with 400Lvolume,adopts hermetic structure.

Configuration of tank

1,Sterile respirator.

2,Thermometer(According to customer requirements).

3,CIP cleaning device.

4,Inlet of seed.

5,Adjustable triangular bracket.

6,Blender

7,Jacket(Miller board or hollow jacket are available according to customer requirements)

8,View lamp(According to customer requirements)

9,Sampling valve.

Main technical parameters
Effective volume L	Dimension of tank D*H	Total height H	Diameter of inlet & outlet mm	Heat preservation layer mm	Motor power KW	Blending speed R/MIN
100	600×550	1700	38	50	0.45	40
200	700×800	1850	38	50	0.55	40
300	800×750	2100	38	50	0.55	40
400	800×800	2150	38	50	0.55	40
500	840×1000	2300	38	50	0.75	40
600	900×1000	2300	38	50	0.75	40

FAQ

1) This is the first time I use this kind of machine, is it easy operate?

There are guide video that show how to use machine and english instruction book send to you with machine.

If there is still have any question, we will provide free professinal guide for you until you could use machine well.

2) If machine have any problem after I ordered it, how could I do?

Free parts send to you in machine warranty period if machine have any problem.

Free after-sales service life for machine, please feel free contact us if your machine have any problem.

3) MOQ ?

Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you.

Welcome to Visit our factory: plz feel free to contact ph,whatsapp +86 13918920854
