Coconut Fiber Extracting Machine With Dryer
Q: Installation (Coconut Fiber Extracting Machine With Dryer)
A: According to clients request, WeiDa machinery can provide installation Technologists to supervise and assist in the assembly and commissioning of the equipment.
Q: What about Warranty? what will we do if the machine is broken now
A: The warranty period for all of WeiDa’s structural and mechanical equipment is normally one year. Wear parts are not covered in warranty unless the component part is found to be flawed.
Q: What should we need to do for if I want to get a suitable machine.
A: Hi, if you want to get the correct and exact selection of the model earlier ,please help us with following information
1).what is your raw material? How about the requires for final product.
2).the capacity (tons per hour )
3).power supply(voltage & frequency)
Q: What could you help me to do for the business ?
A: HIghly appreciate your trust , we can provide you with proposal chart for complete production lines, spot inspection and operator traning according to your demands and the conditions of applied spot , we can help you choose the suitable equipments.
Q: What's your After sales Service
A: All equipment provided by WeiDa Machinery is with the highest standard and very few customer complaint . Should any problems occur, our team of Engineers and Technicians will respond within12 hours of notice by the client. And after selling, we keep monitoring the operation suitation about our machines monthly.
| Model | WKS-1 | WKS-2 | WKS-3 | WKS-4 | WKS-5 | WKS-6 |
Power | 37-45kw | 45-55kw | 75-90kw | 90-110kw | 132-160kw | 160-180kw |
Quantity of Blades | 21 | 24 | 30 | 36 | 42 | 48 |
Rotating Speed of Main Shaft | 1400 | 1400 | 1300 | 1300 | 1200 | 1000 |
Production Capacity(raw material) | 1-2t/h | 2-3t/h | 4-6t/h | 5-8t/h | 8-10t/h | 10-15t/h |
Weight | 2.5t | 3t | 4t | 4.8t | 6t | 9t |
Work Principle
Fiber Open Machine is a kind equipment processing palm fruit bunch, coconut coir and sisal root into fiber. Raw material is sent into the feeding device by conveyor or worker. The blades on high-speed rotating main shaft break the raw material and open the fiber. The residue be separated out by screen mesh, and the fiber be sent out directly from outlet. At the same time, the conveying system can be connected to the outlet, so the outcome fiber could be sent to further process, such as screened, dried, compressed and baled, crushed, etc.
Function
Generally this type machine is electricity powered, but according to customers’ request, it could also be assembled to internal combustion engine powered type, or made into draught movable type. And according to customers’ request, we could also design and produce particular type machine, or assemble conveying system sending material in and out, screening equipment, drying equipment, baling equipment, crushing equipment, briquetting equipment, granulating equipment and so on.
Working Process
1. By worker or conveyor, the raw material is sent to feeding device and come into the machine.
2. The raw material is broken by the blades on the rotating main shaft
3. Breaking Principle:The material is rotated, stirred and rubbed into fiber by machine, come out from outlet.
4. On the rubbing box of machine, there are drain holes, which can drain the impurities from breaking and don't mix with the result fiber;
5.Generally the result fiber still need to be screened one more time, so it can become end fiber.
Zhanjiang Weida Machinery Industrial Co., Ltd, established in 2004, is a professional manufacturer engaged in the research, development, production, sale and service of complete sets equipment for natural rubber, compound rubber, smoked sheet rubber, synthetic rubber, and reclaimed rubber; processing equipment for sisal, hemp, banana fiber, pineapple leaf and so on; juice extractor, plant dehydrator and granulation machine. We locate in Zhanjiang, Guangdong, have convenient transportation access. Dedicated to strict quality control and thoughtful customer service, our experienced staff are available to serve for your requirements at any time and ensure your full satisfaction. Our company has a series advanced equipment, such as large horizontal lathe, longmen milling machine, longmen boring machine, planer, numerical control machining equipment and so on. Our products are very hot sell in all the cities and provinces in China and many countries and regions, such as Vietnam, Myanmar, Cambodia, Thailand, Malaysia, Africa, Europe, South America and so on. We also welcome OEM and ODM orders. No matter selecting a current product from our catalog or seeking engineering assistance for your application, you can contact our customer service center and talk about your sourcing requirements.
