double layers veneer drying dryer machine 2 layers veneer drying
Linyi huida imp.&exp. Co.,ltd is engaged in producing and trading wood working machine for nearly 20 years (factory name is linyi jinlun hot press machinery co.,ltd and shandong feixian jinlun machinery factory ) Out main products is hot press , veneer lathe ,plywood production line ,partical board production line and MDF production ,Many of our products have got CE certificate, national patent ! Our products have been exported to England,Germany ,Philippines, Vietnam, Russia, Malaysia, Thailand, Kazakhstan, India, Indonesia, Iran, Jordan ,Pakistan, Moldova ,Turkey, Ghana and Mexico,all over the world there will be our products Best pre sales service ,service after sales and on site installation , you donot need to worry about anything ! Welcome to visit our factory and feel free to contact us .
Model | BG1324 |
Width of feed inlet | 2400mm |
Max working width | 2200mm |
Thickness of panel/veneer | 3mm |
Working layers | 1 |
Power of heating motor | 5.5kwX7sets |
Power of cooling motor | 5.5kwX1set |
Power of conveyor motor | 3.0kw |
Drying temperature | 90 -130℃ |
Initial moisture | 20-70% |
Final moisture | 8% |
Heating medium | Steam or Thermal oil |
Roller material | Chrome plated |
Daily out put | 7-10m3/24hours |
Size of body(LxWxH) | 18X3.2X1.8m(16m heating room,2m cooling room) |
Weight | 20T |
Delivery | 40F container*3 |
Characteristic:
The machine is used for drying sliced or peeled veneer in the veneer production line with slicer or rotary peeler.
The equipment adopts advantages of all kinds of dryers. .Veneer is conveyed in the middle of two layers of steel rollers and flat after drying. The veneer is fed transversely or longitudinally. It is convenient for collection and store.
The machine consists of inlet, drying area, cooling area, outlet. Heating rooms can be added or lessen according to the production capacity, process and space, in order to improve productivity with lowest investment
Kind reminder:
This machine matches 1T steam boiler, if you need steam boiler, pls inform us we will refresh the offer to you
