Double layers Roller type veneer dryer BG1315

BG1328  Double layers Mesh Veneer Dryer  Product Description    Working width1500mmWokring layers1Length of heating section2000mm/pc*5pcsTransmission motor power2kw*1Motor power of thermal air blower5.5kw*4Heating mediumSaturated

Technical Feature

  • New
  • Veneer dryer
  • Shandong, China (Mainland)
  • YUANPING
  • BG1315
  • 380v 50hz
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$10~40

PRIMARY PARAMETERS

Condition
New
Type
Veneer dryer
Place of Origin
Shandong, China (Mainland)
Brand Name
YUANPING
Model Number
BG1315
Voltage
380v 50hz
Power(W)
24kw
Dimension(L*W*H)
10000x2000x1700mm
Weight
7000kg
Certification
ISO,CE
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas

DETAIL DESCRIPTION

BG1328  Double layers Mesh Veneer Dryer





Product Description







Working width

1500mm

Wokring layers

1

Length of heating section

2000mm/pc*5pcs

Transmission motor power

2kw*1

Motor power of thermal air blower

5.5kw*4

Heating medium

Saturated steam or the thermal oil

Steam pressure

0.5-1.2Mpa

Drying temperature

130-160 ℃

Available veneer thickness

0.2-4mm

Veneer initial moisture content

80%

Veneer final moisture content

8%±2%

Drying efficiency

85%

Overall dimension

10000x2000x1700mm

Weight

7000kg
