Laundry Equipment bed sheet flatwork ironing machine steam heating 1500mm-3300mm
Advantages:
1, For bedsheets, quilts, tablecloth, towel, curtain, bath towel etc.
2, Large diameter(Φ800mm) roller drum,stainless steel, surface is smooth.
3, Frame and auxiliary,high-quality steel carbon structures, strong and durable.
4, Variable frequency, variable speed, according to fabric, moisture, steam supply, etc.
5, Simple control with Start/Stop button.
6. Sealed rotary joints, prevent leakage, safety and reliability, save energy.
7. Three-phase electrical system, overload protection, voltage and short circuit protection, emergency stop switch.
8,The fence and travel switch in the input part, reduce fatigue, misuse and the risk.
9, Pressure roll with guiding ribbons,superior ironing quality,nomex ironing belts.
10, Heated: steam, electric, gas for your choice.
11, Roller quantity: single,double or tripple
if you want to know more about our products / factory department,
you can visit our facebook:
https://www.facebook.com/profile.php?id=100012465934180
you can also visit our linkedin:
https://www.linkedin.com/?trk=360-mainlink
Model | TPI-1600 | TPI-1800 | TPI-2200 | TPI-2500 | TPI-2800 | TPI-3000 | TPI-3300 |
Max Ironing Width(mm) | 1600 | 1800 | 2200 | 2500 | 2800 | 3000 | 3300 |
Roller Diameter(mm) | 800 | 800 | 800 | 800 | 800 | 800 | 800 |
Number of Roller(pcs) | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
Ironing Speed(m/min) | 0-6 | 0-6 | 0-6 | 0-6 | 0-6 | 0-6 | 0-6 |
Steam Consumption(kg) | 50-70 | 50-80 | 60-90 | 70-100 | 80-110 | 90-120 | 100-130 |
Steam Presure(Mpa) | 0.3-0.6 | 0.3-0.6 | 0.3-0.6 | 0.3-0.6 | 0.3-0.6 | 0.3-0.6 | 0.3-0.6 |
Main Motor Power(kw) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
Inverter Power(kw) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
Max Iron Smooth Temperature(°C) | 158/200 | 158/200 | 158/200 | 158/200 | 158/200 | 158/200 | 158/200 |
Heating power(kw) | 22.5 | 24 | 27 | 30 | 32.4 | 34.2 | 34.5 |
Net Length(mm) | 2560 | 2750 | 3550 | 3750 | 4020 | 4220 | 4420 |
Net Width(mm) | 1500 | 1500 | 1280 | 1280 | 1280 | 1280 | 1280 |
Net Height(mm) | 1350 | 1350 | 1300 | 1300 | 1300 | 1300 | 1300 |
Net Weight(kg) | 1500 | 1600 | 1700/2300 | 1800/2600 | 1950/2900 | 2000/3100 | 2100/3200 |
Gross Weight(kg) | 1650 | 1800 | 1900/2500 | 1950/2800 | 2050/3100 | 2200/3300 | 2300/3400 |
