Fermented soybean meal dryer is a single cylinder dryer, can be used for drying of various kinds of slurry, this machine is also suitable for the drying treatment in food, chemical and medicine, etc.the machine is mainly composed by Dryer - Rack - gearing - scraper - limiting device - dip feeding device - hydraulic top tight system - electrical control cabinet - exhaust system .

Work theory of  High efficiency and good quality fermented soybean meal dryer

Fermented soybean meal dryer is a kind dryer that heats the material and evaporates the moisture by indirect heating of steam. Its dryer cylinder ( drum) is a metallic hollow cylinder whose surface is finished and is extremely smooth, driven by the transmission device (gearwheel and pinion), the dryer cylinder rotates in axial direction and the speed can is adjustable. The slurry is preheated in preheating tank, when heated to about 50℃, the slurry will be pumped to the leaching material tank at lower part of the drying cylinder, the drying cylinder submerges about 60-80mm depth, then the surface of the rotary cylinder will be coated with a layer of uniform slurry (the thickness of the film), the steam pressure in the dryer cylinder is 0.15-0.3 Mpa, the slurry is heated on the outside surface of the dryer cylinder, the moisture be exhausted by induced draft fan after evaporation. The drying will be finished when the dryer cylinder rotates one circle, the material piece on the external surface of the dry cylinder is scraped with scraping device and falls to the discharge port for collection.

Characteristic of  High efficiency and good quality fermented soybean meal dryer

The dryer cylinder in contact with the material is made of high grade cast iron subject to ground finishing, with characteristics of anticorrosion and free pollution. This machine adopts conductive heating, there's no heat loss taken by the drying medium, so it is high heat utilization and low energy consumption, usually above 70%. It is also characterized by compact structure, less room taking and convenient cooperation and maintenance, etc. This machine is made by combining with the advantages of the Germany sample machine and in light of the actual situation in China, advanced operational performance is achieved.

TAIDING Drying Equipment Co.,LED is mainly specialized in wood dryer machine/kiln drying wood equipment / wood machinery/ wood chips dryer machine/wood dryer/ fermented soybean meal dryer/grain dryer/sawdust dryer/animal manure dryer/ orgainc fertilizer dryer/animal feed dryer and so on.Pellet machine such as wood pellet machine,sawdust pellet machine,fertilizer pellet machine and crusher,heat generator,dust remover and so on.we can provide you the high quality,high efficiency,low consumption products.we also can customize the complete set of equipments, plan the best project for you,lower labor and low-cost and high efficiency.

1. Pre-sale services:

    1. Select proper equipment model;

    2. Design and manufacture products according to customer' actual requirements;

    3. Arrange for visiting our factory.

2. Services during the sale:

   1. Make sure goods prepared within delivery time;

   2. Pre-check and accept products ahead of delivery;

   3. Prepare documents required to help customer clear the customs.

3. After-sale services:

    1. Assist our customers to prepare for the first construction scheme;

    2. Install, debug and examine the equipment;

    3. Train technical personnel the first-line operators.

If you have any question about High efficiency and good quality fermented soybean meal dryer  ,pls free to contact me.
