Centrifuge sieve

When the equipment running, the starch slurry enters the bottom of the sieve basket, and then under the effect of centrifugal force and gravity, the slurry goes a complex curve movement toward the bigger size direction, even rolling.

Technical Feature

  • China (Mainland)
  • MecKey
  • MKCE500
  • Grain Processing Equipment
  • Engineers available to service machinery overseas
  • Centrifuge sieve
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$20~5

PRIMARY PARAMETERS

Place of Origin
China (Mainland)
Brand Name
MecKey
Model Number
MKCE500
Type
Grain Processing Equipment
After-sales Service Provided
Engineers available to service machinery overseas
Item
Centrifuge sieve
Usage
Fiber separation
Capacity
15-20 m3/h
Material
SS304
Power
18.5-22 kW
Weight
1480 kg
Rotary speed
900-1100 RPM
Warranty
1 year warranty
Tips
Can be used in Wheat starch and potato starch plant
Spare parts
Spare parts for a year

DETAIL DESCRIPTION



Centrifuge sieve

Application

Wheat/cassava/potato/sweet potato starch fiber separation centrifugal sieve.





Description:

The centrifugal sieve is used to separate fiber (residue) in the cassava starch emulsion. It is widely used for cassava starch extraction in large and medium - sized starch production enterprises.

When the equipment running, the starch slurry enters the bottom of the sieve basket, and then under the effect of centrifugal force and gravity, the slurry goes a complex curve movement toward the bigger size direction, even rolling. In the process, the bigger impurities arrive the outer edge of the sieve basket, collecting in the slag collection chamber, whist the starch particle which size is smaller than the mesh fall into the starch powder collection chamber.

The machine has spray nozzle device both in the back and front of the sieve basket. By spraying washing water, the material move speed is accelerated whist the starch particles are easy to separate from the fiber slag.



Characteristics of the equipment



1.  The equipment is made of stainless steel to prevent starch pollution;

2.  The equipment surface is treated in a special process, beautiful and oil & dirt resistance;

3.  The rotating sieve basket is corrected by the authority balancing accuracy to ensure that the equipment running smoothly;

4.  Its mesh is manufactured by special plate, beautiful and durable;

5.  The nozzle passes strict contrast test of pressure and flow;

6.  The devices features big capacity, reasonable allocation of power, high starch extraction rate, easily installed.



Technical Specification



              Model

MKCS500

MKCS650

MKCS850

MKCS1000

Rotary speed                  r/min

900~1100

900~1100

900~1100

900~1100

Screen basket diameter   mm

500

650

850

1000

Power                             kw

11

15

18.5~37

45

Capacity(raw potato)        t/h

10

20

35

>35

Material

SS304

SS304

SS304

SS304

Weight                           kg

1150

1300

1480

1800

Outside dimensions        mm

2300×850×1760

1785×1000×1905

1965×1200×2055

2075×1400×2205
