2017 Best Quality Stainless Steel Gluten Washer Machine/Wheat Flour Washing in Korea
Application of Gluten Washer Machine:
In wheat starch production line, B starch and active protein separated in 3-phase horizontal screw centrifuge is sent to wash in gluten washing drum sieve. In general, washed gluten after 2 or 3 tandem washing is sent to dehydration then.
Features of Gluten Washer Machine:
1. All parts in contact with raw material are made of food-grade stainless steel, which protects materials from outer pollution and increases service life of machine.
2. Large capacity, excellent screening performance, easily installed.
3. Low revolving speed, low energy consumption and great operation safety.
4. This is an perfect machine for large scale wheat starch production line.
Working Principle of Gluten Washer Machine
Wheat flour paste kneaded by dough mixer or other method is sent into rotary drum by feeding device, rolling forward in the drum and completely washed by spray system. There doesn’t exists mesh at the early stage of the drum, while little-size gluten wouldn’t leak and would be rolled to mass.
Send Inquiry
NO. | Item | Parameters |
1 | Model of Main Engine | GTS12 |
2 | Main Power(kW) | 3 |
3 | Diameter of Rotary Drum(mm) | 1200 |
4 | Length of Rotary Drum(mm) | 4200 |
5 | Revolving Speed of Rotary Speed(rpm) | 6 |
6 | Flash Water Pressure (MPa) | 0.3-0.5 |
7 | Capacity(ton/hr) | 20 |
8 | Boundary Dimension(m) | 5.1*1.62*2.4 |
Q1: Is your company a factory or trading company?
A: Our company is a factory in Henan Province ,with export license
and we have done export business over 20 years professionally.
Q2.What is your main business?
A: ZZJH is devoted to starch processing machine. The machine of starch processing line , such as : cassava starch line , cassava flour line , potato starch line , sweet potato line , wheat starch ,sago line and garri line
Q3:Where is your factory located? How can I visit there?
A: Our add: Zhengyun Road and Guanggu Road intersection , Guangwu Town , Zhengzhou City , Henan Province , China.
Warmly welcome to visit us!
Q4: Are your products can be assured ?
A: Our machines are all passed ISO9001:2001 and have CE certificate by SGS, TUV.
Q5: If we show you our layout of factory, can you help us to design the whole process line?
A : Yes, our experienced engineers and technical employees can help you to arrange the layout and installation of whole process line based on your real situation;
Q6: If we have samples of new products, can you help us to analysis and design the machine?
A: Yes, Our technical department can help you to analysis, design and test the new products you offered.
