1.Application Areas:
Emulsion Pump high shear emulsifier pumps Homogenizer
Refined chemistry:
Pigment, dyestuff, plastic auxiliaries, textile auxiliaries, adhesives, resin dispersion, silicon oil dispersion, hot melt adhesive, sealing compound, glue, pulp, finishing agent, surface active agent, carbon black disperse, adhesive-proof agent, mold release agent, deforming agent, fluorine cleaning agent, polishing agent, leather auxiliaries, pigment paste, dispersion wax, bactericide, catalyze, coagulant.
Petrochemical
Lubricant, heavy oil dispersion, diesel oil dispersion, modified asphalt, catalyze, wax dispersion.
Biology & pharmaceuticals:
Injection, medical dispersion, medical paste, health product, mini-capsule dispersion, cell breaker.
Paint & ink:
printing ink, paint, dispersion paint, building coating, nanometer coating, photocureable coating, coating auxiliaries, carbon black disperse, glaze, Alta-mud.
Farm chemicals:
Pesticide, herbicide, medicinal butter, fertilizer, pesticide adjuvant.
Nanometer materials:
Disperse and depolymerization.
Foodstuff industry:
Juice, jam, ice-cream, milk product, food addictive, tea drink, chocolate, bean milk, essence.
Consumer chemistry:
Fluid detergent, face cream, lip paste, face foam, silicon oil dispersion, household essence, skin care products.
Paper making:
Pulp, adhesive, rosin disperse, auxiliaries, resin dispersion.
2. Size table
Type | Power(KW) | Voltage | Rev(RPM) | Flow Rate (M3/h) | Outlet Pressure(MPa) | Material |
SRH-80 | 1.5 | 380V/50Hz | 2900 | 0-1.5 | ≤0.2 | SS304 |
SRH-100 | 2.2 | 380V/50Hz | 2900 | 0-3 | ≤0.2 | SS304 |
SRH-130 | 4 | 380V/50Hz | 2900 | 0-4 | ≤0.2 | SS304 |
SRH-140 | 5.5 | 380V/50Hz | 2900 | 0-5 | ≤0.2 | SS304 |
SRH-165 | 7.5 | 380V/50Hz | 2900 | 0-8 | ≤0.2 | SS304 |
SRH-180 | 11 | 380V/50Hz | 2900 | 0-12 | ≤0.2 | SS304 |
SRH-185 | 15 | 380V/50Hz | 2900 | 0-18 | ≤0.2 | SS304 |
SRH-200 | 22 | 380V/50Hz | 2900 | 0-25 | ≤0.2 | SS304 |
SRH-210 | 30 | 380V/50Hz | 2900 | 0-35 | ≤0.2 | SS304 |
SRH-230 | 45 | 380V/50Hz | 2900 | 0-50 | ≤0.2 | SS304 |
SRH-245 | 55 | 380V/50Hz | 2900 | 0-75 | ≤0.2 | SS304 |
SRH-260 | 75 | 380V/50Hz | 2900 | 0-90 | ≤0.2 | SS304 |
SRH-275 | 90 | 380V/50Hz | 2900 | 0-110 | ≤0.2 | SS304 |
SRH-280 | 132 | 380V/50Hz | 2900 | 0-130 | ≤0.2 | SS304 |
Emulsion Pump high shear emulsifier pumps Homogenizer
