Heavy Duty Dough Mixer/ Japan Dough Mixer/ Wheat Flour Mixer Machine
Features of the wheat flour mixer machine
The mixer adopts plate paddle agitator and is equipped with a high strength vacuum pump. The machine rotates with chain wheel to drive the swing bar in the tank, have the function of mixing and stirring flour.
Hydraulic control and accurate positioning are adopted to open the lid of the hopper and empty the box. The parts and appearance of the hopper are all made of high-quality stainless steel, which meet the requirements of national food hygiene standards.
Working principle
The plate-type blade vacuum dough mixer machine simulates the principle of hand -made dough under vacuum negative pressure.
It increase more than 10-20% water content than normal dough mixer, which can make gluten network form quickly, make the protein structure equilibrium, the end dough is brightness, uniform, flexible, the gluten strength is big, the dough quality markedly improved, dough taste is smooth, high transparency, good elasticity.
Application of the wheat flour mixer machine
It is suitable for making all kinds of pasta products. Such as bun, dumpling skin, wonton skin, ravioli skin, strips, flour cake and so on. The end dough has good tensile strength and no bubbles.
If use the dough to make dumpling, the filling is not easy to break the skin. When cooking, it doesn’t mix soup and doesn’t break the skin.
Technical data
Model | DV-15 | DV-25 | DV-50 | DV-100 | DV-200 |
Vacuum of hopper
| -0.095 Mpa | -0.095 Mpa | -0.095 Mpa | -0.095 Mpa | -0.095 Mpa |
Capacity | 12.5 kg | 25 kg | 50 kg | 100kg | 200 kg |
Rotated speed of blender | 30 rpm | 30 rpm | 30 rpm | 30 rpm | 30 rpm |
Voltage | 220V/ 380V | 380V | 380V | 380V | 380V |
Power | 2.2 kw | 3 kw | 4kw | 7.5 kw | 16 kw |
Dimension | 1100*580*1200 mm | 1380*580*1200 mm | 1580*710*1354 mm | 1800*810*1454 mm | 1960*934* 1734mm |
Weight | 430kg | 480kg | 760kg | 900kg | 1500kg |
More photos of the wheat flour mixer machine
We also have the normal model wheat flour mixer machine as below
