Name: 2-6mm industrial hot air flow flash dryer
Introduction
flash dryer is used for drying materials from moisture 20%-60% to 6%-8%.
It is consist of hot air stove,inlet, steel buffer cylinders pipe, exhaust fan,air lock
and cyclone separator.
1.It is widely used for drying the powdery,laminar materials like wood sawdust,
crop straw,grain stalks etc.
2.It is specially suitable for drying the starch,albumen powder from food
such as corn,potato etc.
3.It is also for drying the granular and spiny materials in chemical products,
medicine and biomass industry.
Working theory
Wet materials are input into the hopper. It uses the varying diameters of
branch segments of pulse tube and continual change of air flow speed
to constantly thrash the material for drying.The fuel boiler generates
hot air which mixes with wet materials and then is sucked into the
pipes by the exhaust blower (fan) quickly. And then hot air is flowing
and going though the curving pipes and buffer (drying chamber)
of dryer, thus wet materials is finished to dry, and the dried materials
are discharged from the outlet with air lock.
Technical parameters
Model | LYHG-100 | LYHG-200 | LYHG-300 |
Productivity (kg/hour) | 400-700 | 800-1300 | 1500-2000 |
Raw materials diameter | <3mm &< 5mm | <3mm&<5mm | <3mm &<5mm |
heating air temperature | 200°C~360°C | 200°C~360°C | 200°C~360°C |
Motor power(kw) | 3-4 KW | 4-5.5 KW | 5.5-7.5 KW |
Weight(kg) | 1200 KG | 1600 KG | 2100 KG |
Features
1.As the raw material particles are suspended in the hot air stream,
the heat transfer between the hot air and particle is rapid.
That ensures efficient moisture removal, even with a short transfer time of 3-5 seconds
2.Once the moisture hot air and particles reach the cyclone separator,
the particles leave the through the base and moist hot air leaves through
the top of the cyclone.The buffer cylinders are to increase particle resonance
time in the hot air stream.
3.The dryer usually uses coal, firewood and gas as heating source.
Combustible gas as the heating resource can save labor 75%.
4.it not only reduces the labor intensity but also can reuse the fuel gas
Drying materials
