2015 GK800M Starch Centrifugal Separator
Description of 2015 GK800M Starch Centrifugal Separator :
When the drum driven the motor runs at full speed, the feed valve automatically opens up and the suspension liquid goes through the feed pipe into the drum, where the liquid phase passes through the filter gauze and the screen openings on the drum and is kicked off by the centrifugal force and flows out of the tangential discharging outlet, while the solid phase is retained inside the drum. When the set time is reached, the feeding stops. After a given period of time of separation and dehydration, the washing valve acts and the cleaning liquid passes through the washing pipe into the drum to wash the filter cake. Upon the completion of washing, further separation is conducted till the required degree of dryness of the cake is reached. Then discharging starts: the scraper holder rotates enabling the scraper to cut into the cake layer and the cake is scraped off and discharged from the material hopper.
Design Features
♦PLC control for long-distance monitoring; touch-screen operation and human-machine dialogue for easy maintenance and operation.
♦ Action elements with automatic electric-pneumatic/hydraulic control.
♦ Driving with hydraulic coupling (GK1250 and bigger) for stable start-up and simple control, effectively protecting the motor from overload-related damage. Optional inverter start-up for variable speed control.
♦ Floating platform with rubber vibration-absorbing foundation; Liquid -damping vibration absorber is also available with excellent effects of absorbing effects, ensures stable operation of the centrifuge and reducing hazards imposed to the equipment and environment from the centrifuge vibration.
♦ Two discharging modes available: chute discharging featuring simple construction; and discharging through scroll conveyor and scraper featuring high catching rate of solid cake and effectively prevent blocking.
Applications of 2015 GK800M Starch Centrifugal Separator
Model GK centrifuge is the filter equipment characterized with continuous running, scraper discharging and intermittent operation, applicable to the separation of the suspension liquid containing medium-sized granules or fine granules (0.01mm~5mm). It can also be used for the separating of the suspension liquid containing short fibers (with the fiber length less than 4mm), with the concentration of the suspension liquid being 10%~60%. With hydraulic and electric joint control mode adopted, this series of centrifuges are capable of high degree of automization, with such working processes as feeding, dehydrating, washing, discharging, etc. being operated manually or by means of PLC for full automatic control. The horizontal scraper discharging centrifuge has good adaptability to the material to be processed and thus can be widely used in such industrial fields as chemical, light industry, food, pharmacy, etc. for the separating of over 100 kinds of substances including ammonia sulphate, sodium sulphate, anthracene, boric acid, starch, pesticide, synthetic resin, sodium cyanide, potassium chloride, sodium bicarbonate, etc.
Techincal parameter of 2015 GK800M Starch Centrifugal Separator
GK(F)/GKH/GKC Series Automatic Horizontal Siphon Scraper Centrifuge --- Properties and Uses: |
GK(F)/GKC Series automatic horizontal scraper discharge centrifuge is a solid-liquid separation equipment which is continuous operation and intermittent discharging. |
| --- Working principle: |
GK(F)/GKC Working principle |
More details of 2015 GK800M Starch Centrifugal Separator
| Jiangsu Peony Centrifuge Manufacturing Co., Ltd. was founded in 1990, located in the famous port town of China—Zhangjiagang. The company specialized in the research and manufacture of Separator Machinery for many years. After years of diligent developing and experience accumulating, the company have became one of the major manufacturers of pharmaceutical & chemical machinery in Jiangsu province and the manufacture base of general-purpose centrifuge. With the Imp. & Exp. license, the company are the vice president of the Chinese Separator Machinery Industry ISOC and the member of Separator Machinery Standardized Technical Committee. Now there are more than 220 employees in the company. Among them, 83 graduated from technical school or University, and 18 gained the title of middle or advanced technical job. Led by science and technology constantly, the company invested great amounts of money to purchase equipments and have established an advanced system of casting, metalworking, assembling, inspecting and testing. Our products, manufacturing process and testing & inspecting means are always the leader of the Separator machinery Industry. The company is always guided by market demands. With the advanced systemic service mode and philosophy, the company provides personal service to every signal case, has professional engineer supplying professional consultation and has established a professional, high efficient service team. Taking customers' each requirement into consideration, the company impresses customers greatly from all over the world, and gains good reputation in the Industry. |
Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time. We are committed to reward you with a better quality in return for our interest in and faith toward. We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
1. FAQ>>About Alibaba Escrow Service
Q------Do You Accept Alibaba Escrow Service?
A------Yes.Alibaba Escrow Service is also acceptable for our company.
That is,after your online order and payment,if we did not follow the agreed delivery time,or after your receipt of the goods,problems occured caused by our quality, you will get payment refund, our credit guarantee amount is $29.000.00
2.FAQ>>About Delivery Terms
Q------What's the delivery terms for making business with us?
A------Usually we send the shipments in FOB term.However, the terms of CIF and C&F are acceptable which depends on preference of clients.
3..FAQ>>About Lead TIme
Q------What's the lead time after placing the order?
A------Usually it takes about 35-45 days after we received you down payment.
However it would depend on our production line schedule (the timing clients place order) and the complication of the items.
4.FAQ>>About Payment Terms
Q------What's the payment terms?
A------By T/T in Advance or Irrevocable L/C as Sight.
Q: Can you send the formula for the products we want to make?
A: Our machines can be used for many kinds of product making, such as Resin, Paint, Adhesive, Cosmetic, Food, Chemicals. There are many kinds of these products, so it's impossible for us to know all the formulas and technologies. We can assist you to find the raw material list you need, and after you place order with us, we can help you to find formula and technology, there will be engineers to teach you how to make the product, and the cost will be on your account.
Q: Do you have machines in stock?
A: Yes, but just the small-scale machines. Machines are different with other products, most of the large-scale machines are designed according to our customers' requirements, different customers have different production requirements, so the technical parameter is different for most machines. On the other hands, most of the our machines will cover a large area, so once the machines are finished, we will effect shipment after QC.
Q: Can you send the detailed drawings of the machine to us before we place order?
A: We can send you a draft drawing of the machines, and after you place order and pay the deposit, our engineer will design the specific technical parameters fo you and send you the detailed drawings. Once you confirm without questions, we will put it into production.
Q: Why does it take at least 20 days to finish the machine?
A: Once receipt the deposit from you, we will design the drawings and make out the list of the materials and accessories for the production. Once the drawings are finished, our workers will start the production, from welding, polishing, assembling, debugging, detection and so on. After finish, they need time to check the machines, if found any possible defect parts, they will return to the production until every part is 100% approved.
Q: Can we pay the balance after we receive the machines and test without problems?
A: It's unnessary to worry about the quality of our machines, we are confident in that. After the machine is finished, we can install and test the machine for you (if you can not come to our factory, we can record a vedio and send to you). Only after you check without problems, we will effect shipment.
