Refrigerated Air Dryer Specification
| Model | AEO-120SG |
| Air flow capacity | 16.0Nm3/min (571cfm) |
| Design pressure | 6-15Bar |
| Design temperature | 100°C |
| Cooling type | Air cooling |
| Dew point | 2-5 °C |
| Compressed air temperature at inlet | 60 °C |
| Refrigerant | R12,R22,R134A,R407C,R410A etc |
| Electricity supply | 220V-1Ph-50Hz |
| Compressor power | 2.57KW |
| Fan motor | 460W |
| Export path | R2-1/2 |
| Dimension (L*W*H) | 1,200*600*1,270mm (47.2*23.6*50.0inch) |
| Packing size | 1.4m3 |
| Weight | 950Kg (2,094Ib) |
Features of the Refrigerated Air Dryers
1.The refrigerated air dryer has a two-stage heat exchange to improve efficiency and energy savings.
2.It offers a high-efficiency 100% copper moisture separator to guarantee an extremely low pressure drop and smooth operation even under heavy working conditions.
3.The refrigerated air dryer has thermally protected cooling fans, and a safety system to prevent compressor damage due to malfunction or high working temperatures.
4.It has self adjusting controls to provide extremely low and constant dew point, while preventing icing.
5.The refrigerated air dryer offers an automatic electronic drain standard with each unit.
6.It has low noise level and features a space saving design.
APPLICATION
General protecton purposes: air quality compliance ISO8571.1; quality 2-3 to remove a lot of water and solid impurities.
Refrigerated Air Dryer MODEL LIST Clik For More Details | ||||
| AEO-100SG | AEO-120SG |
